AOZ52383QI - High-Performance Smart Power Stage

Alpha & Omega Semiconductors

AOZ52383QI Datasheet Preview — Preview of AOZ52383QI PDF

Datasheet Details

Part number	AOZ52383QI
Manufacturer	Alpha & Omega Semiconductors
File Size	2.19 MB
Description	High-Performance Smart Power Stage
Datasheet	AOZ52383QI-AlphaOmegaSemiconductors.pdf

AOZ52383QI Product details

Description

The AOZ52383QI is a general-purpose Smart Power Stage (SPS) for computing notebook CPU power, consisting of two asymmetrical MOSFETs and an integrated driver for high current, high frequency, and DC-DC converter.

Features

4.5 V to 25 V power supply range.
45 A continuous output current - Up to 65 A for 20 ms instantaneous current @ 14 V VIN - Up to 60 A for 20 ms instantaneous current @ 22 V VIN - Up to 80 A for 10 µs instantaneous current.
Optimized for switching frequency up to 1 MHz.
Integrated current monitor output signal.
Integrated temperature monitor output signal.
Fault Indicator.
VCC33 and PVCC5 Under-Voltage LockOut (UVLO).
Zero.
