AD1959 - PLL/Multibit DAC

Analog Devices

📥 Download Datasheet

AD1959 Datasheet Preview — Preview of AD1959 PDF

Datasheet Details

Part number	AD1959
Manufacturer	Analog Devices
File Size	108.00 KB
Description	PLL/Multibit DAC
Datasheet	AD1959_AnalogDevices.pdf

AD1959 Product details

Description

28-Lead Small Outline Package 28-Lead Small Outline Package Evaluation Board Package Option RS-28 RS-28 on 13" Reels PIN CONFIGURATION CCLK 1 CLATCH 2 RESET 3 LRCLK 4 BCLK 5 SDATA 6 DVDD 7 28 27 26 25 24 CDATA MUTE ZERO FILTB AVDD OUTL AD1959 23 22 AGND1 TOP VIEW DGND 8 (Not to Scale) 21 FLTR SCLK0 9 MCLK 10 XOUT 11 XIN 12 SCLK1 13 SCLK2 14 20 19 18 17 16 15 OUTR AGND0 LF1 LF0 PGND PVDD 4 REV.

Features

5 V Stereo Audio DAC System Accepts 16-Bit/20-Bit/24-Bit Data Supports 24 Bits, 192 kHz Sample Rate Accepts a Wide Range of Sample Rates Including: 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, and 192 kHz Multibit Sigma-Delta Modulator with Data Directed Scrambling Single-Ended Output for Easy.
