AD779

14-Bit 128 kSPS Complete Sampling ADC

AD779 Features

* AC and DC Characterized and Specified (K, B, T Grades) 128k Conversions per Second 1 MHz Full Power Bandwidth 500 kHz Full Linear Bandwidth 80 dB S/N+D (K, B, T Grades) Twos Complement Data Format (Bipolar Mode) Straight Binary Data Format (Unipolar Mode) 10 M⍀ Input Impedance 16-Bit Bus Interface (

AD779 General Description

PRODUCT HIGHLIGHTS The AD779 is a complete, multipurpose 14-bit monolithic analog-to-digital converter, consisting of a sample-hold amplifier (SHA), a microprocessor compatible bus interface, a voltage reference and clock generation circuitry. The AD779 is specified for ac (or “dynamic”) parameter.

AD779 Datasheet (220.05 KB)

Preview of AD779 PDF

Datasheet Details

Part number:

AD779

Manufacturer:

Analog Devices ↗

File Size:

220.05 KB

Description:

14-bit 128 ksps complete sampling adc.
