AD8508 Datasheet, Amplifiers, Analog Devices

✔ AD8508 Features

PSRR: 100 dB minimum CMRR: 105 dB typical Very low supply current: 20 μA per amplifier maximum 1.8 V to 5 V single supply or ±0.9 V to ±2.5 V dual supply Rail-to-rail inp

✔ AD8508 Application

Pressure and position sensors Remote security Bio sensors IR thermometers Battery-powered consumer equipment

PDF File Details

Analog Devices manufacturer logo and representative part image

Part number:

AD8508

Manufacturer:

Analog Devices ↗

File Size:

724.89kb

Download:

📄 Datasheet

Description:

Zero input crossover distortion amplifiers. The AD8505/AD8506/AD8508 are single, dual, and quad micropower amplifiers featuring rail-to-rail input/output swings while operating

📥 Download PDF (724.89kb)
