ADG1411 Datasheet, Switch, Analog Devices

ADG1411 Features

• Switch 1.5 Ω on resistance 0.3 Ω on-resistance flatness 0.1 Ω on-resistance match between channels Continuous current per channel LFCSP: 250 mA TSSOP: 190 mA Fully specified at +12 V, ±15 V, a

PDF File Details

Part number:

ADG1411

Manufacturer:

Analog Devices ↗

File Size:

400.36kb

Download:

📄 Datasheet

Description:

Quad spst switch. The ADG1411/ADG1412/ADG1413 are monolithic complementary metal-oxide semiconductor (CMOS) devices containing four independently selec

ADG1411 Application

• Applications APPLICATIONS Automated test equipment Data acquisition systems Battery-powered systems Sample-and-hold systems Audio signal routing Vid
