ADL5906 Datasheet, Detector, Analog Devices

ADL5906 Features

• Detector
• Accurate rms-to-dc conversion from 10 MHz to 10 GHz
• Single-ended ±1.0 dB dynamic range: 67 dB at 2.14 GHz
• No balun or external input matching required

PDF File Details

Part number:

ADL5906

Manufacturer:

Analog Devices ↗

File Size:

6.29MB

Download:

📄 Datasheet

Description:

10 mhz to 10 ghz 67 db trupwr detector. The ADL5906 is a true rms responding power detector that has a 67 dB measurement range when driven with a single-ended 50 Ω source. T

ADL5906 Application

• Applications
• Power amplifier linearization/control loops
• Transmitter signal strength indication (TSSI)
• RF instrumentat
