ADP1148 - Step-Down Switching Regulators

L The ADP1148 is part of a family of synchronous step-down switching regulator controllers featuring automatic sleep mode to maintain high efficiencies at low output currents. These devices drive external complementary power MOSFETs at O switching frequencies up to 250 kHz using a constant off-time .

ADP1148 Features

* FUNCTIONAL BLOCK DIAGRAM Operation From 3.5 V to 18 V Input Voltage Ultrahigh Efficiency > 95% ADJUSTABLE Low Shutdown Current Current Mode Operation for Excellent Line and Load PWR SIGNAL VERSION VIN P-DRIVE N-DRIVE GND GND SENSE(+) VFB SENSE(

* ) 3 1 14 12 11 8 9 7 Transient
