ADV3000 Datasheet, Switch, Analog Devices

✔ ADV3000 Features

3 inputs, 1 output HDMI/DVI links Enables HDMI 1.3-compliant receiver 4 TMDS channels per link Supports 250 Mbps to 2.25 Gbps data rates Supports 25 MHz to 225 MHz pixel

✔ ADV3000 Application

Multiple input displays Projectors A/V receivers Set-top boxes Advanced television (HDTV) sets GAME CONSOLE

PDF File Details

Analog Devices manufacturer logo

Part number:

ADV3000

Manufacturer:

Analog Devices ↗

File Size:

1.01MB

Download:

📄 Datasheet

Description:

3:1 hdmi/dvi switch. The ADV3000 is an HDMI™/DVI switch featuring equalized TMDS inputs and pre-emphasized TMDS® outputs, ideal for systems with long cabl
