APM2301A Datasheet, Mosfet, Anpec Electronics

APM2301A Features

• Mosfet
• -20V/-2.8A, RDS(ON)=72mΩ(typ.) @ VGS=-10V RDS(ON)=98mΩ(typ.) @ VGS=-4.5V
• Super High Dense Cell Design
• Reliable and Rugged
• Lead Free and Green Dev

PDF File Details

Part number:

APM2301A

Manufacturer:

Anpec Electronics

File Size:

177.31kb

Download:

📄 Datasheet

Description:

P-channel mosfet. D S G Top View of SOT-23 S Applications

Power Management in Notebook Computer, Portable Equipment and Battery Powered Syst

APM2301A Application

• Applications
• Power Management in Notebook Computer, Portable Equipment and Battery Powered Systems Ordering and Marking Information G D P
