HV460WU2-600 Datasheet - BOE

HV460WU2-600 TFT LCD

OF CHANGES DATE Initial Release 2012.07.18 PREPARED Du Yufan SPEC. NUMBER B2010-8002-O (2/3) SPEC. TITLE HV460WU2-600 Product Specification PAGE 2 of 24 A4(210 X 297) PRODUCT GROUP TFT LCD REV P0 ISSUE DATE 2012.07.18 Contents No ITEM Page REVISIONS HISTORY 2 CONTENTS 3 1 GENERAL .

HV460WU2-600 Features

* 1.3 Applications 1.4 General Specification 2 ABSOLUTE MAXIMUM RATINGS 6 3 ELECTRICAL SPECIFICATIONS 7 3.1 TFT LCD Open Cell 4 INTERFACE CONNECTION 8 4.1 Open Cell Input Signal & Power 4.2 LVDS Interface 5 SIGNAL TIMING SPECIFICATIONS 11 5.1 Timing Parameters 5.2 Signal Timing Waveform
