BP2866BJ, BP2866AJ Datasheet - BPS

BP2866BJ Non-isolated Buck Offline LED Driver

BP2866XJ is a high precision Buck constant current LED driver. The device operates in critical conduction mode and is suitable for 85Vac~265Vac universal input offline LED lighting. The BP2866XJ integrates a 500V power MOSFET, with proprietary MOSFET driving technique. It doesn’t need VCC capacitor .

BP2866BJ Features

* No VCC Capacitor and Startup Resistor

* Integrated HV JFET for IC Power Supply

* Internal 500V Power MOSFE

BP2866AJ-BPS.pdf

This datasheet PDF includes multiple part numbers: BP2866BJ, BP2866AJ. Please refer to the document for exact specifications by model.
BP2866BJ Datasheet Preview Page 2

Datasheet Details

Part number:

BP2866BJ, BP2866AJ

Manufacturer:

BPS

File Size:

237.56 KB

Description:

Non-isolated buck offline led driver.

Note:

This datasheet PDF includes multiple part numbers: BP2866BJ, BP2866AJ.
Please refer to the document for exact specifications by model.
