BP3166D - High Precision PSR Constant Current LED Driver

Product Overview

BPS

BP3166D High Precision PSR Constant Current LED Driver by BPS - Datasheet Preview — Datasheet preview – BP3166D

Datasheet Details

Part number	BP3166D
Manufacturer	BPS
File Size	412.21 KB
Description	High Precision PSR Constant Current LED Driver
Datasheet	BP3166D Datasheet
Additional preview pages of the BP3166D datasheet.

Product details

Description

The BP3166D is a high precision primary-side feedback and regulation controller for LED lighting, it operates in constant current control mode and is designed to work in inductor current discontinuous conduction mode and especially suitable for flyback convertor under universal input.

Features

No VCC capacitor and no starting resistance.
Integrated HV JFET for Power Supply.
No Auxiliary winding for sensing and supplying.
Universal input voltage.
±5% LED Output Current Accuracy.
LED Short.
