BP3177DF - Isolated Low PF Dimmable LED Driver

Product Overview

BPS

BP3177DF Isolated Low PF Dimmable LED Driver by BPS - Datasheet Preview — Datasheet preview – BP3177DF

Datasheet Details

Part number	BP3177DF
Manufacturer	BPS
File Size	196.86 KB
Description	Isolated Low PF Dimmable LED Driver
Datasheet	BP3177DF Datasheet
Additional preview pages of the BP3177DF datasheet.

Product details

Description

The BP3177DF is an isolated low PF dimmable LED driver controller, compatible with PWM or analog dimming signal for Constant Current Reduction (CCR) dimming, to provide high-precision and flicker-less light output.

Features

Wide dimming range from 5% to 100%, compatible with PWM or analog dimming signal, and support dim-to-off.
Tight LED current reference(±3%).
Good current tolerance in deep dimming.
No output current overshoot.
Built-in line and load regulation.
Multiple protections.
LED open and short protection.
CS short protection.
Over Temperature Protection Typical.
