BP5912B

Color Temperature Switch LED Driver

BP5912B Features

* Integrates switching state detection circuits

* Built-in two 0.5A/400V silicon controlled rectifier

* Fixed two kinds of color temperature switch

* VDD short protection

* Available in SOP-8 package Applications

* LED ceiling lamp

* LED Panel light

* LED Bulb

* O

BP5912B General Description

The BP5912B is a special color temperature switch LED driver,the BP5912B integrates two 0.5A/400V silicon controlled rectifier,realize color temperature switch function by detecting the LED driver switching waveform directly , the BP5912B maximally simplify the periphery components number,ensure the.

BP5912B Datasheet (457.87 KB)

Preview of BP5912B PDF

Datasheet Details

Part number:

BP5912B

Manufacturer:

BPS

File Size:

457.87 KB

Description:

Color temperature switch led driver.
