BP9938F

Non-isolated Buck Offline LED Driver

BP9938F Features

* No VCC Capacitor and Startup Resistor

* Internal 500V Power MOSFET

* Integrated HV JFE

BP9938F General Description

BP9938X is a high precision Buck constant current LED driver. The device operates in critical conduction mode and is suitable for 85Vac~265Vac universal input offline LED lighting. The BP9938X integrates a 500V power MOSFET. With proprietary MOSFET driving technique. It doesn’t need VCC capacitor an.

BP9938F Datasheet (186.07 KB)

Preview of BP9938F PDF

Datasheet Details

Part number:

BP9938F

Manufacturer:

BPS

File Size:

186.07 KB

Description:

Non-isolated buck offline led driver.
