ADS7803 Datasheet, Converter, Burr-Brown Corporation

ADS7803 Features

• Converter q LOW POWER: 10mW plus Power Down q SIGNAL-TO-(NOISE + DISTORTION) RATIO OVER TEMPERATURE: 69dB min with fIN = 1kHz 66dB min with fIN = 50kHz q FAST CONVERSION TIME: 8.5µs Including Acq

PDF File Details

Part number:

ADS7803

Manufacturer:

Burr-Brown Corporation

File Size:

99.96kb

Download:

📄 Datasheet

Description:

Autocalibrating/ 4-channel/ 12-bit analog-to-digital converter. The ADS7803 is a monolithic CMOS 12-bit analogto-digital converter with internal sample/hold and fourchannel multiplexer. It is desig

ADS7803 Application

• Applications Conversion results are available in two bytes through an 8-bit three-state output bus. The ADS7803 is available in a 28-pin plastic DI
