BC107B
DESCRIPTION
Collector Emitter Voltage Collector Base Voltage Emitter Base Voltage Collector Current Continuous Power Dissipation at T a=25ºC Derate above 25ºC Power Dissipation at T c=25ºC Derate above 25ºC Operating And Storage Junction Temperature Range THERMAL CHARACTERISTICS Junction to Ambient in free air Junction to Case SYMBOL VCEO VCBO VEBO IC PD PD Tj, Tstg BC107 45 50 6.0 BC108 25 30 5.0 200 300 1.72 750 4.29
- 65 to +200 BC109 25 30 5.0 UNIT V V V m A m W m W/ ºC m W m W/ ºC ºC
Rth (j-a) Rth (j-c)
583 233
ºC/W ºC/W
.. ELECTRICAL CHARACTERISTICS (Ta=25ºC unless specified otherwise ) DESCRIPTION
SYMBOL TEST CONDITION V IC=2m A, IB=0 Collector Emitter Voltage CEO VEBO IE=10µA, IC=0 Emitter Base Voltage ICBO VCB=45V, IE=0 Collector Cut Off Current
BC107 >45 >6 <15
BC108 >25 >5 <15
BC109 >25 >5 <15 <4
UNIT V V n A n A µA µA
VCB=25V, IE=0 VCB=45V, IE=0, Ta=125ºC VCB=25V, IE=0, Ta=125ºC DC Current Gain h FE IC=10µA, VCE=5V B Group C Group IC=2m A, VCE=5V BC107 BC108 BC109 A Group B...
