V7803-500-SMT Datasheet, Regulator, CUI

V7803-500-SMT Features

• Regulator
• 500 mA current output
• high efficiency up to 96%
• no heat sink required
• SMT package
• remote on/off control
• low ripple and noise

PDF File Details

Part number:

V7803-500-SMT

Manufacturer:

CUI

File Size:

540.45kb

Download:

📄 Datasheet

Description:

Non-isolated switching regulator. NON-ISOLATED SWITCHING REGULATOR FEATURES

500 mA current output

high efficiency up to 96%

no heat sink
