PAC121GTL - HIGH PERFORMANCE GTL TERMINATION NETWORK

PAC121GTL Description

CALIFORNIA MICRO DEVICES PAC560GTL High Performance GTLTermination Network for Socket 370 Processors .

PAC121GTL Features

* 24 terminations in a single package
* 5 chip solution for all 119 GTL terminations
* High speed termination network
* Center ground pin placement reduces ground bounce and eases board layout
* Very low cross-talk
* Saves board space and reduces assem

PAC121GTL Applications

* High Performance Servers
* High Performance Desk Top Systems
* Intel Celeron™ and Pentium™ CPUs Application Information High speed microprocessors demand unique, high speed bus termination. The PACGTL Termination Network provides 24 terminations per package and meets the r

📥 Download Datasheet

Preview of PAC121GTL PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
PAC121GTL
Manufacturer
California Micro Devices Corp
File Size
251.99 KB
Datasheet
PAC121GTL_CaliforniaMicroDevicesCorp.pdf
Description
HIGH PERFORMANCE GTL TERMINATION NETWORK
