Part number: CR6236
Manufacturer: Chip Rail
File Size: 244.35KB
Download: 📄 Datasheet
Description: High Precision CC/CV Primary-Side PWM Power Switch
Up to 5% Precision for Constant Voltage Regulation and Constant Current Regulation at Universal AC input Primary-side Sensing and Regulation Without TL431 and Opto-couple.
Cell Phone /Digital Cameras Charger Small Power Adaptor
General Description
CR623X is a high performance offline PWM pow.
CR623X is a high performance offline PWM power switch for low power AC/DC charger and adaptor applications. It operates in primary-side sensing and provides constant voltage (CV) and constant current (CC) regulation without TL431 and opto-coupler. A .
Image gallery
