MX6058

The MX6058 is N-Channel Enhancement Mode Power MOSFET designed by ChipSourceTek.

Product Overview

ChipSourceTek

📥 Download Datasheet

MX6058 N-Channel Enhancement Mode Power MOSFET by ChipSourceTek - Datasheet Preview — Datasheet preview – MX6058

Datasheet Details

Part number	MX6058
Manufacturer	ChipSourceTek
File Size	1.02 MB
Description	N-Channel Enhancement Mode Power MOSFET
Datasheet	MX6058-ChipSourceTek.pdf
Additional preview pages of the MX6058 datasheet.

Product details

Description

The MX6058 uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge.

Features

VDS =60V，ID =8A.
RDS(ON)(Typ. )13mΩ @ Vgs=10V Schematic diagram.
High density cell design for ultra low Rdson.
Fully characterized Avalanche voltage and current k.
