C1587-AL - Flyback Transformers

C1587-AL Description

Document 458 Flyback Transformers ForNationalSemiconductor LM5070 PoE Interface * 7 Watt * Flyback transformers for 7 W PoE applicat.

C1587-AL Applications

* Designed to operate in continuous mode at 250 kHz with an input of 36 
*  72 Vdc
* 1500 Vrms isolation from primary and bias to secondary Core material Ferrite Terminations  RoHS tin-silver over tin over nickel over phos bronze. Other terminations available at additional co

📥 Download Datasheet

Preview of C1587-AL PDF

Datasheet Details

Part number
C1587-AL
Manufacturer
Coilcraft
File Size
95.62 KB
Datasheet
C1587-AL-Coilcraft.pdf
Description
Flyback Transformers
