DO-35 - Subminiature Circuit Protector

📥 Download Datasheet

Datasheet preview – DO-35

Datasheet Details

Part number DO-35
Manufacturer Cooper Electronic Technologies
File Size 78.21 KB
Description Subminiature Circuit Protector
Datasheet download datasheet DO-35 Datasheet
Additional preview pages of the DO-35 datasheet.

📁 Similar Datasheet

  • DO-35-Glass - Zener Voltage Regulator Diodes (Motorola)
  • DO-001S - Digital Oscillator Controller (Gleam)
  • DO-201AD - FS PKG Code P3 (Fairchild Semiconductor)
  • DO-201AE - DIMENSIONS (Fairchild Semiconductor)
  • DO-204AH - GLASS ZENER DIODES 500 MILLIWATTS 1.8.200 VOLTS (Motorola)
  • DO-214BA - Ultrafast Recovery Rectifiers (Vishay)
  • DO-214xx - Ultrafast Recovery Rectifiers (Vishay)
  • DO-219AB - SMF (Vishay Siliconix)
  • DO-41 - Hermetically Sealed Glass Axial Package (CDIL)
Other Datasheets by Cooper Electronic Technologies
  • DO-35-xx - Subminiature Circuit Protector

Full PDF Text Transcription

Click to expand full text
Bussmann® Subminiature Circuit om Protector Axial Lead Overcurrent Protection w w Catalog Symbol: DO-35 Voltage Rating: 32V ac/dc Interrupting Rating: 50 Amp AC, Power Factor = 1.0 50 Amp DC, Battery Source Physical Size: EIA/JEDEC Publication 95; Outline DO-35; Axial Leads Agency Approvals: U.L. Recognized, Std. 248-14, File E19180, Guide JDYX2 CSA Component Acceptance, File 53787, Class 1422-30 General Information: • Economical overcurrent protection. • Compatible with wave soldering. • Unaffected by rigorous board washing operations. • Excellent environmental integrity. • One time positive disconnect. Interruption Time: 10 Sec. max. @ 250% rated current 1 mSec. typ.
