Bussmann®
Dual-Element, Time-Delay Glass Fuse om
For ⁄Ω¢∑ ≈ 1⁄Ω¢∑ (6.4mm ≈ 31.8mm)
w
w
a D . w
S a t
e e h
U 4 t
.c
MDQ MDQ-V
6.76mm .266" 38.10mm 1.500" (REF)
Dimensional Data
31.8mm 1.25" (±0.031)
32.82mm (± .79) 1.292" (± .031)
6.4mm .25" (±0.003)
Catalog Symbol: MDQ ⁄Ω¢∑ ≈ 1⁄Ω¢∑ (6.3mm ≈ 32mm) 3AG Dual-Element, Time-Delay Agency Approvals: U.L. Listed, Std. 248-14 ⁄Ω¡§-7A, Guide JDYX, File E19180 U.L. Recognized, 7.5-30A Guide JDYX2, File E19180 CSA Certified, Class 1422-01, File 47233 Body Material: Glass Ferrule Material: Brass Ferrule Plating: Nickel
General Information: • Formerly designated 3AG. • For circuits with high inrush currents. • Mounts in Buss HTB panel-mounted HB series PC board fuseholders, series 8000 fuseblocks and ⁄Ω¢∑ clips.
