CY3672 Datasheet - Cypress Semiconductor

CY3672, Three-PLL General Purpose FLASH Programmable Clock Generator

CY22381 Three-PLL General Purpose FLASH Programmable Clock Generator .
Configurable clock output C Ground Reference crystal input or external reference clock input Reference crystal feedback (float if XTALIN is driven by.

datasheet Preview Page 1 from Datasheet4u.com

CY3672_CypressSemiconductor.pdf

CY3672 Datasheet Preview — Preview of CY3672 PDF

Datasheet Details

Part number:

CY3672

Manufacturer:

Cypress Semiconductor

File Size:

143.57 KB

Description:

Three-PLL General Purpose FLASH Programmable Clock Generator

Features

* Three integrated phase-locked loops
* Ultra-wide divide counters (eight-bit Q, eleven-bit P, and seven-bit post divide)
* Improved linear crystal load capacitors
* Flash programmability
* Field programmability
* Low-jitter, high-accuracy outputs

Applications

* Supports numerous low-power application schemes and reduces EMI by allowing unused outputs to be turned off
* Adjust crystal drive strength for compatibility with virtually all crystals
* External frequency select option for PLL1, CLKA, and CLKB
* Industry standard
