21041-PB Datasheet - Digital

21041-PB, PCI Ethernet LAN Controller

w w a D .w S a t e e h U 4 t .c om Digital Semiconductor 21041 PCI Ethernet LAN Controller Product Brief February 1996 .
The Digital Semiconductor 21041 PCI Ethernet LAN Controller is a single-chip master, direct memory access (DMA) Ethernet LAN controller with a direct.

datasheet Preview Page 1 from Datasheet4u.com

21041-PB_Digital.pdf

21041-PB Datasheet Preview — Preview of 21041-PB PDF

Datasheet Details

Part number:

21041-PB

Manufacturer:

Digital

File Size:

107.17 KB

Description:

PCI Ethernet LAN Controller

Features

* Offers a single-chip Ethernet controller for PCI local bus: - Provides glueless connection to PCI bus - Contains an onchip integrated attachment unit interface (AUI) port and a 10BASE-T transceiver
* Implements the same architecture as the 21040 to allow use of unified drivers

Applications

* The 21041 is optimized for PCI-based systems. A direct connection to 10BASET is made through the twisted-pair port. From the AUI port, the 21041 can connect to 10BASE2, 10BASE5, or 10BASE-F using the appropriate media access unit (MAU) and circuitry. The 21041 is a high- performance, highly integrat
