DMB2227A
COMPLEMENTARY NPN / PNP SMALL SIGNAL SURFACE MOUNT TRANSISTOR
Features
• • • • • • Complementary Pair Epitaxial Planar Die Construction One 2222A Type (NPN), One 2907A Type (PNP) Ideal for Low Power Amplification and Switching Lead Free By Design/RoHS Compliant (Note 2) "Green Device" (Note 3)
A
C1 E1 C2
SOT-26 Dim
B C
Min 0.35 1.50 2.70 – – 2.90 0.013 1.00 0.35 0.10 0°
Max 0.50 1.70 3.00 – – 3.10 0.10 1.30 0.55 0.20 8°
Typ 0.38 1.60 2.80 0.95 0.55 3.00 0.05 1.10 0.40 0.15 –
A B
B1
E2
B2
C D
NEW PRODUCT
Mechanical Data
• • • • • • • • Case: SOT-26 Case Material: Molded Plastic, “Green” Molding Compound. UL Flammability Classification Rating 94V-0 Moisture Sensitivity: Level 1 per J-STD-020C Terminals: Finish - Matte Tin annealed over Copper leadframe.
