DSM80101M - NPN TRANSISTOR

Diodes

📥 Download Datasheet

DSM80101M Datasheet Preview — Preview of DSM80101M PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	DSM80101M
Manufacturer	DIODES
File Size	375.49 KB
Description	NPN TRANSISTOR
Datasheet	DSM80101M-Diodes.pdf

DSM80101M Product details

Features

Integrates one NPN Transistor (Q1) and two Switching Diodes (D1, D2) in a Single Compact Package.
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2).
Halogen and Antimony Free. “Green” Device (Note 3) Mechanical Data.
Case: SOT26.
Case Material: Molded Plastic, “Green” Molding Compound. UL Flammability Classification Rating 94V-0.
Moisture Sensitivity: Level 1 per J-STD-020.
Terminals: Matte Tin Finish Annealed over Copper Leadframe (Lead-Free Plating). S.
