NA555S Datasheet, Timer, Diodes

NA555S Features

• Timer
• Timing from microseconds to hours
• Astable or monostable operation
• Adjustable duty cycle
• TTL compatible output can source or sink up to 200mA

PDF File Details

Part number:

NA555S

Manufacturer:

DIODES ↗

File Size:

722.29kb

Download:

📄 Datasheet

Description:

Precision timer. These devices are precision timing circuits capable of producing accurate time delays or oscillation. In the timedelay or monostable
