MG5424 - X-Band Magnetron

Compact, rugged, lightweight, fixed frequency magnetron, electrically the same as M5187.

pulse GENERAL DATA Electrical Operating frequency .

.

.

.

.

Typical peak output power .

.

.

.

Cathode .

.

.

.

.

.

.

.

.

.

Heater voltage (see note 1) .

.

.

.

Heater current at 6.3 V (see note 2) .

Cathode pre-h

www.DataSheet.co.kr E2V Technologies MG5424 X-Band Magnetron The data should be read in conjunction with the Magnetron Preamble.

MAXIMUM AND MINIMUM RATINGS (Absolute values) These ratings cannot necessarily be used simultaneously, and no individual rating should be exceeded.

Min Max Heater voltage (see note 1) .

.

.

.

.

5.7 6.9 V Heater starting current (peak) .

.

.

.

3.0 A Anode voltage (peak) .

.

.

.

.

.

.

8.6 kV Anode current (peak) .

.

.

.

.

.

.

5.0 10 A Input power (
