BZW06-14B, BZW06-28B Datasheet - EIC discrete Semiconductors

BZW06-14B, BZW06-28B, BIDIRECTIONAL TRANSIENT SUPPRESSOR

BZW06-5V8B SERIES VBR : 6.8 - 440 Volts PPK : 600 Watts .

datasheet Preview Page 1 from Datasheet4u.com

BZW06-28B_EICdiscreteSemiconductors.pdf

BZW06-14B Datasheet Preview — This datasheet PDF includes multiple part numbers: BZW06-14B, BZW06-28B. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

BZW06-14B, BZW06-28B

Manufacturer:

EIC discrete Semiconductors

File Size:

66.13 KB

Description:

BIDIRECTIONAL TRANSIENT SUPPRESSOR

Note:

This datasheet PDF includes multiple part numbers: BZW06-14B, BZW06-28B.
Please refer to the document for exact specifications by model.

Features

* :
* 600W surge capability at 1ms
* Excellent clamping capability
* Low zener impedance
* Fast response time : typically less www. DataSheet4U. com then 1.0 ps from 0 volt to VBR(min)
* Typical IR less then 1µA above 10V
* Pb / RoHS Free BIDIRECTIONAL TRANSIENT SUPPRESSOR D2 0

Applications

* For uni-directional without B suffix Electrical characteristics apply in both directions MAXIMUM RATINGS Rating at 25 °C ambient temperature unless otherwise specified. Rating Peak Pulse Power for 1 msec. Exponential Pulse Steady State Power Dissipation ( L=10mm ) Storage Temperature Range Symbol
