3.0SMCJ180C Features
* :
* 3000W peak pulse power capability with a 10/1000µs waveform
* Excellent clamping capability
* Low inductance
* High temperature soldering : 250 °C/10 seconds at terminals.
* Built-in stran relief
* Pb / RoHS Free MECHANICAL DATA
* Case : SMC Molded plastic
* Epoxy
Datasheet Details
3.0SMCJ180C, 3.0SMCJ11C
EIC
48.26 KB
Surface mount transient voltage suppressor.
This datasheet PDF includes multiple part numbers: 3.0SMCJ180C, 3.0SMCJ11C.
Please refer to the document for exact specifications by model.
