s Low-loss RF filter for mobile telephone EGSM s
0,075
0,075 0,675
1 2 3 4
s s s s
and PCN system , receive path Usable passband: Filter 1 (EGSM): 35 MHz Filter 2 (PCN): 75 MHz Unbalanced to balanced operation of both filters Impedance transformation from 50 Ω to 150 Ω for both filters Suitable for GPRS Class 1 to 12 Ceramic package for Surface Mounted Technology (SMT)
bottom view
10
0,35
0,95 0,325
0,68
0,4
9
8
7
6
5
side view
2,5
2,0
top view
Terminals
s Ni, gold-plated
Dime.
