ETA9897, Ultra-Low Power PMU

ETA9897 Ultra-Low Power PMU with 30V Linear Charger and 5V Boost Converter .
ETA9897 is an ultra-low power PMU with 2 modules: a 30V single cell Li+ battery linear charger and a 5V boost synchronous converter with true-shutoff.

datasheet Preview Page 1 from Datasheet4u.com

ETA9897-ETA.pdf

ETA9897 Datasheet Preview — Preview of ETA9897 PDF

Datasheet Details

Part number:

ETA9897

Manufacturer:

ETA

File Size:

545.07 KB

Description:

Ultra-Low Power PMU

Features

* Ultra low IQ when No switching: 1.2uA
* 30V input standoff voltage
* 4.2V charge termination voltage
* Charge current programmable, up to 1.2A
* Output Disconnect and SCP at 5V output
* 5V/0.4A Output Power
* Up to 94% Efficiency for boost converter
* Operation over

Applications

* TWS BT earbuds charge case
* Bluetooth application
* Battery powered IOT module
* Power Bank TYPICAL APPLICATION VIN Li+ Battery Pack 10uF 2.2uH 4.7uF 6 VIN 5VOUT 1 ETA9897 7 BAT ENBST 2 4 TS STAT 3 8 SW ISET 5 GND 9 10uF 2K Riset VOUT ENBST VIN ORDERING INFORMATION P
