C1602 -10
1.FEATURE:
LCD MODE BACKLIGHT TYPE CHARACTER FONTS CONTROLLER POWER SUPPLY FOR LCM LED BACKLIGHT INPUT EL BACKLIGHT INPUT EL INVERTER
16 CHARS× 2 LINES
1/16 DUTY
1/4 BIAS
2.ELECTRICAL CHARACTERISTICS:
TN/STN LED/EL BACKLIGHT 5× 8 DOTS (WITH CURSOR) S6A0069 OR EQUIVALENT DC +5V DC +5V ITEM SUPPLY VOLTAGE FOR LCD INPUT VOLTAGE INPUT HIGH VOL INPUT LOW VOL
OUTPUT HIGH VOL OUTPUT LOW VOL SUPPLY CURRENT
SYM CONDITION MIN TYP MAX UNIT Ta=0? 4.6 V VDD-V Ta=25? 4.4 V O Ta=50? 4.2 V VI VIH VIL VOH VOL IDD IF PD VDD=5v Ta=25? Ta=25? 4.5 2.2 0 2.4 5.0 3.0 100 500 5.5 VDD 0.6 0.4 4.5 V V V V V mA mA mW
3.ABSOLUTE MAXIMUM RATINGS :
ITEM OPERATING TEMP. STORAGE TEMP.
