DK225A-14 Datasheet - ETC

DK225A-14 Disk Drive

DK225A-14 Specifications www.DataSheet4U.com Page 1 of 2 DK225A-14 2.5-inch Disk Drive Specifications & Jumper Settings MODEL INTERFACE FORMATTED CAPACITY DK225A-14 ATA-3 1.44 Gbytes PARAMETERS CYLINDERS HEADS BYTES PER SECTOR SECTORS PER TRACK ROTATIONAL SPEED AVERAGE LATENCY 4188 16 512 63 4,464 rpm 7 ms TRANSFER RATE INTERNAL (Disk-Buffer) BUFFER-HOST (Host-Buffer) BUFER SIZE 5.7~9.0 Mbytes/ sec 16.6 MB/s max. (PIO Mode4, DMA Mode2) 128 Kbytes SEEK TIMES AVERAGE MAXIMUM MINIMUM 12 ms 24 .

DK225A-14 Datasheet (119.23 KB)
