TC1602A-09
■ Series
Display Format 16 Characters X 2 Lines
Drive Method
1/16 Duty , 1/5 Bias
LCD Type
STN Blue
LED Backlight
white
Viewing direction
Operating Temperature
■ Power supply
6 00
0 ~+50
■ Electrical Characteristics
ITEM
Supply Voltage For Logic Supply Voltage For LCD Input High Voltage Input Low Voltage output High Voltage output Low Voltage
Power Supply Current With B/L
Symbol
VDD-VSS VDD-V0
VIH VIL VOH VOL IDD ILED
Condition
----IOH=-0.1mA IOL=0.1mA VDD=5.0V VDD=5.0V
Standard value Min. Typ. Max. 4.5 5.0 5.5
-- 4.7 -2.2 -- 5.0 -0.3 -- 0.6 2.4 -- 5.0 -- -- 0.4 -- 1.5 3.
TC1602A-09 Datasheet
