EBS12UC6APS - 128MB SDRAM S.O.DIMM

Name: EBS12UC6APS
SKU: EBS12UC6APS-230571

Elpida Memory

📥 Download Datasheet

EBS12UC6APS Datasheet Preview — Preview of EBS12UC6APS PDF

Datasheet Details

Part number	EBS12UC6APS
Manufacturer	Elpida Memory
File Size	145.18 KB
Description	128MB SDRAM S.O.DIMM
Datasheet	EBS12UC6APS_ElpidaMemory.pdf

EBS12UC6APS Product details

Description

The EBS12UC6APS is 16M words × 64 bits, 1 bank Synchronous Dynamic RAM Small Outline Dual In-line Memory Module (S.O.DIMM), mounted 4 pieces of 256M bits SDRAM (EDS2516APTA) sealed in TSOP package.

Features

Fully compatible with 8 bytes S. O. DIMM: JEDEC standard outline.
144-pin socket type small outline dual in line memory module (S. O. DIMM)  PCB height: 31.75mm (1.25inch )  Lead pitch: 0.80mm.
3.3V power supply.
Clock frequency: 100MHz/133MHz (max. ).
LVTTL interface.
Data bus width: × 64 non-ECC.
Single pulsed /RAS.
4 Banks can operates simultaneously and independently.
Burst read/write operation and burst read/sing.
