DS850DC-3, DS850DC-3_ds650dc-3_ds850dc-3_ds_1198193043 - AC-DC / Distributed Power Front-End 1U

Emerson

Datasheet Details

Part number	DS850DC-3, DS850DC-3_ds650dc-3_ds850dc-3_ds_1198193043
Manufacturer	Emerson
File Size	568.97 KB
Description	AC-DC / Distributed Power Front-End 1U
Datasheet	DS850DC-3_ds650dc-3_ds850dc-3_ds_1198193043_Emerson.pdf
Note	This datasheet PDF includes multiple part numbers: DS850DC-3, DS850DC-3_ds650dc-3_ds850dc-3_ds_1198193043. Please refer to the document for exact specifications by model.

1U X 2U Form Factor.
15.4W/ in3.
+12Vdc Output.
+3.3vdc Stand-By (5V standby - consult factory).
No Minimum Load Required.
Hot Plug Operation.
N + 1 Redundant.
Internal OR’ing Fets.
Active Current Sharing 2PSU Shared from 30% to 100% 4PSU Shared from 20% to100%.
Built-in Cooling Fan (40mm x 28mm).
I2C Communication Interface Bus.
EERPOM for FRU Data.
Red/Green Bi-Color LED Status.
