MB23S, MB22S - Surface Mount Glass Passivated Bridge Rectifier

Eris

MB23S Description

MB22S THRU MB220S Surface Mount Glass Passivated Bridge Rectifier MBS .

MB23S Features

* ‧Schottky Brrier Chip ‧Low Power Loss,High Efficiency ‧Ideally Suited for Automatic Assembly ‧Surge Overload Rating to 50A Peak ‧Plastic Case Material has UL Flammability Classification Rating 94V-0 Ordering Information Part No. MB22S THRU MB220S MB22S THRU MB220S-H Remark General Halogen Free Pa

📥 Download Datasheet

MB23S Datasheet Preview — This datasheet PDF includes multiple part numbers: MB23S, MB22S. Please refer to the document for exact specifications by model.

Datasheet Details

Part number: MB23S, MB22S
Manufacturer: Eris
File Size: 399.07 KB
Datasheet: MB22S-Eris.pdf
Description: Surface Mount Glass Passivated Bridge Rectifier
Note: This datasheet PDF includes multiple part numbers: MB23S, MB22S.
Please refer to the document for exact specifications by model.
