ST16C1550 - (ST16C1550 / ST16C1551) 2.97V TO 5.5V UART WITH 16-BYTE FIFO

Product Overview

Exar Corporation

Datasheet Details

Part number	ST16C1550
Manufacturer	Exar Corporation
File Size	428.50 KB
Description	(ST16C1550 / ST16C1551) 2.97V TO 5.5V UART WITH 16-BYTE FIFO
Datasheet	ST16C1550 Datasheet
Additional preview pages of the ST16C1550 datasheet.

Product details

Description

The ST16C1550 and ST16C1551 UARTs (here on denoted as the ST16C155X) are improved versions of the SSI 73M1550 and SSI 73M2550 UART with higher operating speed and lower access time.

Features

may be tailored by external software to meet specific user requirements. An internal loopback capability allows onboard diagnostics. The baud rate generator can be configured for either crystal or external clock input with the exception of the 28 pin ST16C1551 package (where an external clock must be provided). Each package type, with the exception of the 28 pin ST16C155X, provides a buffered reset output that can be controlled through user software. DMA monitor signals TXRDY/RXRDY are not avail.
