XR-1004 - General Purpose Low Pass Filter

Product Overview

Exar

Part number	XR-1004
Manufacturer	Exar
File Size	125.13 KB
Description	General Purpose Low Pass Filter
Datasheet	XR-1004 Datasheet
Note	This datasheet PDF includes multiple part numbers: XR-1004, XR-1000. Please refer to the document for exact specifications by model.
Additional preview pages of the XR-1004 datasheet.

The XR-1000 is a general purpose 4th order low pass filter utilizing switched capacitor (SCF) circuit techniques.

Switched Capacitor Circuit Techniques Single 5 Volt Operation Low External Parts Count No Precision Components Necessary Low Power Operation 50:1/100:1 Clock to Cutoff Frequency Options 8-Pin/14-Pin Packag.
