1SMA5936B Datasheet - FCI

1SMA5936B Surface Mount Zener Diode

1.5 WATTS Surface Mount Zener Diode Mechanical Dimensions .055(1.40) .062(1.60) .098(2.50) .114(2.90) .078(2.00) .096(2.44) .030(0.76) .060(1.52) .157(4.00) .181(4.60) .006(.152) .012(.305) .002(.051) .008(.203) .188(4.80) .208(5.28) SMA/DO-214AC Dimensions in inches and (millimeters) Fea.

1SMA5936B Features

* ¬ For surface mounted applications ¬ 1.5 W power dissipation ¬ Ideally suited for automated assembly processes Mechanical Data ¬ Case: Molded plastic SMA/DO-214AC ¬ Epoxy: UL 94V-0 rate flame retardant ¬ Terminals: Solderable per MIL-STD-750 method 2026 ¬ Polarity: cathode band ¬ Mounting position:

1SMA5936B Datasheet (435.67 KB)

Preview of 1SMA5936B PDF
1SMA5936B Datasheet Preview Page 2 1SMA5936B Datasheet Preview Page 3

Datasheet Details

Part number:

1SMA5936B

Manufacturer:

FCI

File Size:

435.67 KB

Description:

Surface mount zener diode.
