C2328
NPN
AUDIO POWER AMPIFIER APPLICATIONS *Complement to A928 *Collector Dissipaition PC=1W *3 Watt Output Application
ABSOLUTE MAXIMUM RATINGS(TA=25
Characteristic Symbol Rating Unit
Collector-Base Voltage
VCBO
V
Collector-Emitter Voltage VCEO
V
Emitter -Base Voltage
VEBO
V
Collector Current
Ic
A
Collector Dissipation
Pc
W
Junction Temperature
TJ
Storage Temperature
TSTG -55 ~ +150
)
ELECTRCAL CHARACTERISTICS(TA=25 )
Characteristic
Symbol Test Conditions Min Typ Max Unit
Collector-Base Breakdown Voltage BVCBO IC= 100µA,IE=0
V
Collector-Emitter Breakdown Voltage BVCEO IC= 10mA,IB=0
V
Emitter -Base Breakdown Voltage BVEBO IE= 1mA,IC=0
V
Collector Cut-off Current
ICBO
V
C2328 Datasheet
