DM7414 datasheet, input equivalent, Fairchild Semiconductor

DM7414 Description

This device contains six independent gates each of which performs the logic INVERT function. Each input has hysteresis which increases the noise immunity and transforms a slowly changing input signal to a fast changing, jitter free output. Ordering .
