HP4936DY - N-Channel Power MOSFET

HP4936DY Description

HP4936DY Data Sheet December 2001 5.8A, 30V, 0.037 Ohm, Dual N-Channel, Logic Level Power MOSFET This power MOSFET is manufactured using an innovativ.

HP4936DY Features

* Logic Level Gate Drive
* 5.8A, 30V
* rDS(ON) = 0.037Ω at ID = 5.8A, VGS = 10V
* rDS(ON) = 0.055Ω at ID = 4.7A, VGS = 4.5V
* Related Literature - TB334, “Guidelines for Soldering Surface Mount Components to PC Boards” Symbol D1(8) D1(7) Ordering Information
