P6N60 FQP6N60

P6N60 Description

DataSheet.in FQP6N60 April 2000 QFET FQP6N60 600V N-Channel MOSFET General .
These N-Channel enhancement mode power field effect transistors are produced using Fairchild’s proprietary, planar stripe, DMOS technology.

P6N60 Features

* 6.2A, 600V, RDS(on) = 1.5Ω @VGS = 10 V Low gate charge ( typical 20 nC) Low Crss ( typical 10 pF) Fast switching 100% avalanche tested Improved dv/dt capability D ! " G G! DS ! " " " TO-220 FQP Series ! S Absolute Maximum Ratings S

📥 Download Datasheet

Preview of P6N60 PDF
datasheet Preview Page 2 datasheet Preview Page 3
