BDS102 Features
* Ideal for printed circuit boards Applicable for automative insertion High surge current capability Solder Dip 260 oC, 40 seconds Mechanical Data Case: DFS Epoxy meets UL-94V-0 Flammability rating Terminals: Matte tin plated (E3 Suffix) leads, solderable per J-STD-002B and JESD22-B102D Polarity: As
Datasheet Details
BDS102, BDS101
First Silicon
197.25 KB
Single phase surface mount bridge rectifier.
This datasheet PDF includes multiple part numbers: BDS102, BDS101.
Please refer to the document for exact specifications by model.
