BDS106, BDS101, SINGLE PHASE SURFACE MOUNT BRIDGE RECTIFIER

SEMICONDUCTOR TECHNICAL DATA DF005S ~ DF10S Miniature Glass Passivated Single-Phase Surface Mount Bridge Rectifiers Reverse Voltage 50 to 1000 Volts.

datasheet Preview Page 1 from Datasheet4u.com

BDS101-FirstSilicon.pdf

BDS106 Datasheet Preview — This datasheet PDF includes multiple part numbers: BDS106, BDS101. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

BDS106, BDS101

Manufacturer:

First Silicon

File Size:

197.25 KB

Description:

SINGLE PHASE SURFACE MOUNT BRIDGE RECTIFIER

Note:

This datasheet PDF includes multiple part numbers: BDS106, BDS101.
Please refer to the document for exact specifications by model.

Features

* Ideal for printed circuit boards Applicable for automative insertion High surge current capability Solder Dip 260 oC, 40 seconds Mechanical Data Case: DFS Epoxy meets UL-94V-0 Flammability rating Terminals: Matte tin plated (E3 Suffix) leads, solderable per J-STD-002B and JESD22-B102D Polarity: As

Applications

* General purpose use in ac-to-dc bridge full wave rectification for SMPS, Lighting Ballaster, Adapter, Battery Charger, Home Appliances, Office Equipment, and Telecommunication applications Maximum Ratings and Electrical Characteristics (TA=25oC unless otherwise noted) Parameter Symbols DF005S D
