FT6236 - Self-Capacitive Touch Panel Controller

Description

1 2.1 ARCHITECTURAL OVERVIEW 1 2.2 MCU 2 2.3 OPERATION MODES 2 2.4 SERIAL INTERFACE 3 2.4.1 I2C 3 3 ELECTRICAL SPECIFICATIONS 4 3.1 ABSOLUTE MAXIMUM RATINGS 4 3.2 DC CHARACTERISTICS 4 3.3 AC CHARACTERISTICS 5 3.4 I/O PORTS CIRCUITS 6 3.5 POWER ON/RESET/WAKE SEQUENCE 6 4 PIN CONFIGURATIONS 9 5 P

Features

  • Self-Capacitive Sensing Techniques support single point touch and gesture or two point touch.
  • Absolute X and Y coordinates or gesture.
  • 1 point and gestures / 2 points supported.
  • High immunity to RF and power Interferences.
  • Auto-calibration: Insensitive to Capacitance and Environ- mental Variations.
  • Built-in Enhanced MCU.
  • FT6236 supports up to 22 or 28 channels of sensors /drivers.
  • FT6336 supports up to 36 channels of sensors /drivers.
  • FT6436L support.

📥 Download Datasheet

Datasheet preview – FT6236

Datasheet Details

Part number FT6236
Manufacturer FocalTech Systems
File Size 644.66 KB
Description Self-Capacitive Touch Panel Controller
Datasheet download datasheet FT6236 Datasheet
